Sequence Valves

Sequence Valves: Precision Control, Seamless Performance!

A sequence valve is a type of hydraulic valve used in fluid power systems to control the sequence in which different parts of a hydraulic circuit are activated. Essentially, it ensures that certain operations or actions are performed in a specific order.

Example:

In a manufacturing system with two cylinders, you might want the first cylinder to extend fully before the second cylinder begins its motion. A sequence valve can be used to ensure that the first cylinder is fully extended (i.e., pressure reaches a certain level) before the second cylinder is allowed to operate.

Overall, sequence valves are important for ensuring that hydraulic systems operate in a controlled, sequential manner, improving efficiency and preventing damage to equipment.

How does it work?

• Setting the Pressure: A sequence valve is typically set to open and allow fluid flow only once a certain pressure threshold is reached. This ensures that the first operation is completed before the next one begins.
• Controlling Multiple Actuators: In systems with multiple actuators (such as cylinders or motors), the sequence valve can control the timing and order of actuation, ensuring the proper sequence of operations, such as in a manufacturing process or in a hydraulic lifting system.
• Backflow Prevention: Sequence valves are usually one-way valves that prevent backflow of the fluid, ensuring that the fluid only flows in one direction and the system remains in the correct sequence.

Common applications:

• Hydraulic Presses: Ensures cylinders operate in the correct order.
• Lifting Systems: Manages the sequence of hydraulic cylinders in cranes and lifts.
• Conveyor Systems: Synchronizes the operation of multiple actuators.
• Injection Moulding: Controls the sequence of actions in moulding machines.
• Machine Tools: Manages tool changers and other components in CNC machines.
• Aviation: Controls landing gear and flight surface operations.
• Construction Equipment: Synchronizes hydraulic functions in excavators and bulldozers.
• Manufacturing Lines: Ensures smooth assembly processes in production lines.
• Oil & Gas: Controls drilling equipment and safety systems.
• Agricultural Machinery: Manages hydraulic operations in tractors and harvesters.

Technical Specifications & Downloads

Each product page includes downloadable technical specifications in PDF format for easy reference. Click on the product of your choice and navigate to the download tab.

Order Your Sequence Valves at Flowfit Today!

With over 9,000 satisfied global customers, Flowfit has built a reputation for quality and reliability. We offer UK & Worldwide delivery, ensuring you receive the hydraulic products you need.

For more information, call 01584 876 033 or email sales@flowfitonline.com to speak with our expert team
